Aerfoam Adaptor 180 (F) - 150 (M)

Article number: 188979

The Aerfoam Adaptor 180 (F) – 150 (M) enables direct connection between DN180 and DN150 Aerfoam insulated ducts. The female end fits over the DN180 duct, while the male end inserts into the DN150 duct, ensuring a secure and airtight transition. Manufactured from PE, the adaptor is lightweight, durable, and quick to install on site.

  • Quick push-fit installation, no special tools required
  • Secure and airtight DN180 to DN150 transition
  • Lightweight PE construction for easy handling on site
View all specifications

All media

Aerfoam Adaptor 180 (F) - 150 (M)
Aerfoam insulated ductwork system

Specifications

General

Product Name
Aerfoam Adaptor 180 (F) - 150 (M)
GTIN
8713645248776
Part number
100023188979
Type
Adaptors
Trade name
Aerfoam

Technical

Comm. Dimension
150 mm / 180 mm
Shape
Circular
Color
Black
Airflow direction
Supply / extract

Dimensions

Length gross
216 mm / 8.5 inch
Height
114 mm / 4.5 inch
Width
216 mm / 8.5 inch
Net weight
0.2 kg / 0.4 lbs

Logistical

Intrastat
39259080
Base unit packaging
Unpacked
Packaging / Trade length
216 mm / 8.5 inch
Packaging / Trade height
114 mm / 4.5 inch
Number per packaging
1
Gross weight
0.2 kg / 0.4 lbs
Packaging / Trade width
216 mm / 8.5 inch

Performance

CE string
-
